Packing an impressive output of 1700 lumens in an incredibly compact housing, the EVO 1700 is tailored specifically for daily commuting in urban settings.
Without the need for a remote control, the EVO 1700SD connects directly to your bike’s Shimano Di2 system (wireless unit).
But please note the light is NOT compatible with SHIMANO E-BIKE SYSTEMS.
You will need a mount for this light, suggest MJ6272
Effortlessly adjust your light settings through Shimano Di2 buttons, as accessible as shifting gears.
**Paring Guide:**Initial Paring: Single click any button on the shifters to activate the SHIMANO Di2 system, then long press the light button for 1 second until the indicator flashes blue to enter pairing mode. Position the light to the rear derailleur within 30 cm. The indicator is constantly blue for 3 seconds, confirming a successful pairing.
**Note:**Before pairing, ensure your SHIMANO Di2 system has at least two unassigned buttons available to fully utilize product features.
First Use:
The light will be locked, rapidly flashing red light when you press the buttons.
To Unlock: press and hold the power biutton for 3 seconds to unlock the light.
To lock the light, why? Traveling etc will not allow the light to be bumped and turn on the light.
To Lock: when the light is off, press and hold the power button for 3 seconds to enter locked mode. [The light will be locked when the red light is rapidly flashing when you press the buttons.
NOTE: After unlocking the light, reconnect it to the Shimano Di2 system to enable the control
Features:
- Compatible with Shimano Di2 system (wireless unit), can be controlled via the Di2 button.
- Unique combination of up-close low beam and far-reaching high beam.
- Cut-off low beam, glare-free for oncoming road users.
- Customize lighting setting through Magicshine APP.
- USB-C rechargeable.
- Lock function to avoid mis-operation.
- Memory function saves the last selected mode.
- Robust aluminum housing for efficient heat management and optimum performance.
| Mode |
|
Lumens |
Time H:Min |
| |
Low |
200 Lm |
11:00 |
| Low Beam |
Medium |
400 Lm |
05:30 |
| |
High |
800 Lm |
03:00 |
| |
Low |
400 Lm |
06:00 |
| High Beam |
Medium |
800 Lm |
03:00 |
| |
High |
1700 Lm |
02:00 |
| Flash |
Day Flash |
0-1700 Lm |
05:00 |
| |
Night Flash |
400-1700 Lm |
03:30 |
Specifications:
- Max Output: 1700 Lumens
- Max Runtime: 11 Hours
- Shimano Di2 Compatible: Support
- Battery Source: 4000mAh
- Charger: USB C
- Waterproof: IPX 6
- Warranty: 2 years
Whats in the box:
- EVO1700SD Shimano Di2 Compatible Bike Light
- USB-C charging cable
- Tether
- User manual
