X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
Click image to open expanded view
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black
X-LAB AD7 105 Di2 12sp Black

X-LAB AD7 105 Di2 12sp Black

Price
$5,489.99
Size:XS
This item is temporary out of stock














































































Model AD7 105 Di2
Frame X-LAB Carbon Frame, UDH Compatible
Fork X-LAB Carbon Fork, 100x12mm Thru-axle
Stem Branta Carbon Integrated
Handlebar
Seatpost XDS Carbon Seatpost, Aero Shape
Rear Derailleur Shimano 105 Di2 RD-R7150
Front Derailleur Shimano 105 Di2 FD-R7150
Shifters Shimano 105 Di2 ST-R7170
Brakes Shimano 105 BR-R7170
Cassette Shimano 105 CS-R7101, 11-34T
Crankset Branta Aluminum Power Meter Crankset, 52-36T, 24mm Steel Spindle, w/Apple Find My Anti-Theft Technology
Bottom Bracket T47 24mm
Rotors Shimano SM-RT70, F:160mm R:140mm
Chain Shimano CN-M7100
Wheelset Branta C45 SL, Carbon Rim, PSR Wing20 Aero Spoke
Tires Branta R630F 700x30C, 60TPI
Saddle FIZIK Aidon, Manganese Rail
Weight 8.44KG (Size M)
































































































































Frame Size XS S M L XL
A Seat Tube Length (mm) 470 495 520 540 565
B Top Tube Length (mm) 504 523 540 559 579
C Head Tube Length (mm) 105 118 130 148 171
D Seat Tube Angle (deg) 75 75 74 73 73
E Head Tube Angle (deg) 71 72 73 73 73
F Chainstay Length (mm) 410 410 410 410 410
G Wheelbase (mm) 975 977 982 992 1007
H Fork Rake/Offset (mm) 53 53 45 45 45
I BB Drop (mm) 72 72 70 70 70
J Stack (mm) 510 525 540 558 580
K Reach (mm) 368 376 387 395 405
L Front Center (mm) 575 582 583 592 607
Trail (mm) 67 62 62 61 59
















































Components Size XS S M L XL
Stem 90 90 100 100 120
Handlebar 360 360 380 380 400
Crankset 165 165 170 170 172.5
Seat Post 310 310 310 310 310





















Sizing Size XS S M L XL
Recommended Rider Height 148–158 cm
4'10"-5'2"		 158–168 cm
5'2"-5'6"		 168–176 cm
5'6"-5'9"		 176–183 cm
5'9"-6'0"		 183–191 cm
6'0"-6'3"
